Tattoo Pen Beauty Device PCBA – Customizable Circuit Board for Permanent Makeup & Microblading with Speed Control & Stroke Adjustment
No.YQQX015
- Precision Motor Control – High‑Efficiency Driver for DC Coreless or Rotary Tattoo Motors. Supports Speed Range 3,000–10,000 RPM with 5–10 Adjustable Levels Via PWM or Analog Voltage.
- Adjustable Needle Stroke – Built‑in Stroke Length Control (1.5mm–4.0mm) Compatible with Most Cartridge Needle Systems. Enables Precise Pigment Deposition for Eyebrows, Lips, and Eyeliner.
- Battery & Charging Management – Single‑Cell Li‑ion (3.7V) or 2‑Cell (7.4V) Support. USB‑C Fast Charging (5V/2A) with Over‑Charge, Over‑Discharge, and Short‑Circuit Protection. Real‑Time Battery Level Display Via LED or OLED.
- Intuitive User Interface – Capacitive Touch or Mechanical Buttons for Power, Speed +/‑, and Stroke Selection. Bright LED Indicators or Optional 0.96″ OLED Screen Showing Speed, Stroke, Battery Percentage.
- Ergonomic & Portable – Compact PCB Design (as Small as 18×60mm) Fits Inside Pen‑Shaped Housings. Low Standby Current (<20µA) Extends Battery Life. Optional Vibration Feedback for Button Press.
(0 Reviews)
0 Sold
Product Overview
The Tattoo Pen Beauty Device PCBA is a high‑performance circuit board designed for permanent makeup machines (microblading pens, PMU devices). It drives a DC motor to produce rapid needle oscillation, controls the stroke length, manages battery charging, and provides a user‑friendly interface. Whether for professional salons or home‑use cosmetic tattoo pens, this PCBA delivers smooth, adjustable, and reliable operation.
We Offer Full Customization Services: Schematic Design, PCB Layout, Component Sourcing, and PCBA Assembly. Contact Us with Your Specific Requirements.
