Scooter Dashboard PCBA – LCD/LED Display Board with Speedometer, Battery Indicator, Headlight Control & Bluetooth for Electric Scooters & E‑Bikes
- Real‑Time Riding Data – Displays speed (km/h or mph), battery voltage / percentage, odometer (trip & total), and assist level (1‑5). Optional current consumption (amps) and estimated remaining range.
- Backlit LCD or LED Segment Display – High‑contrast LCD (with white/blue backlight) or bright LED 7‑segment digits. Sunlight‑readable and anti‑fog design for outdoor use. Auto‑adjust backlight intensity based on ambient light (optional photocell).
- Integrated Controls – Onboard tactile or capacitive touch buttons: power on/off, headlight switch, assist level +/-, walk mode (6km/h push assist), and trip reset. Ergonomic layout for thumb operation.
- Communication & Sensor Inputs – Reads data via UART (from motor controller), Hall speed sensor, or wireless (Bluetooth). Supports standard protocols (e.g., KU63, Lishui, VESC). Optional GPS module for speed and navigation.
- Smart Features – Bluetooth 5.0 (optional) for smartphone app: ride tracking, firmware OTA updates, custom assist mapping, and USB charging port (5V/0.5A) for phone charging.
- Applications – Suitable for: electric scooters (adult & kids), e‑bikes (city, folding, fat‑tire), self‑balancing scooters, go‑karts, and DIY electric vehicle projects. Works with 24V, 36V, 48V, or 60V battery systems (via step‑down converter to 5V/12V dashboard supply).
Product Overview
The Scooter Dashboard PCBA is a multifunctional display and control board designed for electric scooters, e‑bikes, and light electric vehicles. It integrates an LCD or LED display, backlight control, push‑buttons, communication interfaces (UART, Hall sensor, Bluetooth), and a step‑down power supply (from main battery to 5V/12V) onto a compact PCB that mounts inside the handlebar console.
Riders need clear, real‑time information – speed, battery level, assist mode – plus convenient controls (lights, walk assist) without taking their hands off the handlebars. This PCBA enables manufacturers to produce waterproof (IP65 optional), sunlight‑readable dashboards that enhance safety and user experience for daily commuting, leisure riding, and shared e‑scooter fleets.
