Medical Motherboard Reverse Engineering & PCBA Prototyping – High-Precision PCB Cloning & Sampling for Diagnostic Imaging, Patient Monitors & Life Support Systems
- Ultra-High Precision Cloning – Supports Multi-Layer PCB Duplication (4 to 32+ Layers) with Min. Trace/Space Down to 3mil/3mil and Aperture Tolerance Strictly Controlled Within ±0.05mm, Ensuring 1:1 Electrical Performance Match with Original Boards.
- Medical-Grade Compliance Ready – Full Adherence to ISO 13485 Quality Management Systems, IEC 60601 Safety Standards, and FDA 21 CFR Part 820 Design Controls; Qualified Raw Materials Meeting UL94-V0 Flammability Rating.
- Full Turnkey Service – From PCB Cloning (Gerber/BOM/Schematics Extraction), Component Sourcing, SMT/THT Assembly, to Functional Validation and Accelerated Aging Testing – One-Stop Solution for Medical Device OEMs.
- Non-Destructive Reverse Engineering – X-Ray/3D CT Scanning for HDI Boards (Up to 30 Layers) Capturing Internal Traces, Blind/Buried Vias, and Impedance-Matched Parameters Without Damaging Valuable Original Boards.
- Legacy Equipment Sustainment – Extend Lifespan of Discontinued Medical Systems (CT Scanners, MRI, Infusion Pumps, Ventilators) By Cloning Obsolete or Out-of-Production PCBs; 12-24 Months Technical Support Available.
Product Overview
Medical Motherboard Reverse Engineering & PCBA Prototyping provides a complete solution for medical device manufacturers, hospital engineering departments, and equipment maintenance providers to replicate, upgrade, or produce replacement PCBs for diagnostic imaging, patient monitoring, and life support systems. Whether you need to clone a legacy board from a discontinued CT scanner, reverse engineer a competitor‘s design for benchmarking, or produce small-batch prototypes for clinical trials, our reverse engineering services ensure electrical performance, mechanical fit, and regulatory compliance are fully preserved — or even improved.
Contact Information
Submit your original PCB (or high-resolution photos), desired quantity, and application requirements for a free feasibility assessment and quotation.
