Electric Massage Gun PCBA – High‑Power Brushless Motor Driver with 6 Speeds, Pressure Sensor, OLED Display & Li‑ion Battery Management
- High‑Power BLDC Motor Driver – Supports 12V–24V Brushless DC Motors with Up to 30A Peak Current, Delivering Stall Torque Up to 25kg·cm and 2800–3600 RPM Adjustable Speed Range (6 Preset Levels) for Deep Muscle Tissue Penetration.
- Precise Pressure & Stall Detection – Integrated Hall‑based or Strain‑Gauge Pressure Sensor Monitors Real‑time Applied Force (0–30kg Range); Automatic Speed Adjustment Under High Load to Prevent Motor Stall; LED Indicator Warns When Excessive Pressure Is Detected, Protecting Both Motor and User Muscle Tissue.
- Smart Battery Management – Supports 2–6S Li‑ion Batteries (7.4V–22.2V) with High‑Current 5A Quick Charging Via USB‑C or DC Barrel Jack. Comprehensive Protection: Over‑Charge, Over‑Discharge (Cell‑Level), Over‑Current, Short‑Circuit, and Temperature‑Based Charging Current Throttling.
- Intuitive User Interface – 0.96″ or 1.3″ OLED Display Shows Real‑time Speed Level (RPM), Battery Percentage, Pressure Intensity Bar Graph, Stall Warning, and Operating Time. Multi‑Color LED Ring for Speed/Pressure Visual Feedback; 1–3 Mechanical or Touch Buttons for Power, Speed ±, and Mode Selection.
- All‑in‑One Turnkey Design – Compact PCB Layout (as Small as 30×60mm) with Integrated Wireless Charging (Qi Optional) and Bluetooth Module (App Control). Features Low‑idle Current (<15mA), Auto‑sleep After 30s Inactivity, and Silent Drive with Soft Start/Stop – Ideal for Handheld, Portable High‑Intensity Massage Devices.
Product Overview
The Electric Massage Gun PCBA Is a High‑Performance, Fully Customizable Circuit Board Assembly Engineered Specifically for Modern Percussive Therapy Devices (Massage Guns). It Integrates a High‑Current Brushless DC (BLDC) Motor Driver, Precision Pressure Sensing, Smart Li‑ion Battery Management, an Intuitive User Interface, and Optional Wireless Connectivity Into a Compact Form Factor. Designed for Both Professional Athletes and Home Users, This PCBA Delivers Deep Tissue Penetration, Adjustable Intensity, and Safe, Long‑Lasting Operation, Enabling Manufacturers to Create Reliable, Feature‑rich Massage Guns That Stand Out In the Rapidly Growing Percussive Therapy Market, Which Is Projected to Grow at a CAGR of 8.5% from 2024 to 2030.
The Percussive Therapy Market Continues to Expand as Consumers Increasingly Seek Portable, Drug‑free Muscle Recovery Solutions. Key Drivers Include Rising Health Awareness, the Growth of Home Fitness, and Professional Adoption by Physical Therapists and Sports Trainers. Our PCBA Helps you Capture This Demand with Advanced Features Like Stall‑Prevention Control, Real‑time force Monitoring, and App‑Connected Usage Tracking.
