Cleaning Equipment PCBA – Programmable Control Board for Ultrasonic Cleaners, Pressure Washers, Steam Cleaners & Carpet Cleaners
No.YQQX023
- Multi‑Mode Cleaning Control – Supports Ultrasonic (25kHz–120kHz), High‑Pressure Pump (Up to 3000 PSI), Steam Generator (PTC with NTC Feedback), and Brush Motor (DC/AC). Selectable Cleaning Modes: Standard, Gentle, Intensive, Pulse, and Eco.
- Intelligent Timer & Scheduling – Digital Timer (0–99 Minutes) with Audible Completion Alarm (Buzzer). Optional Real‑Time Clock (RTC) for Scheduled Start/Delay Start (Up to 24h In Advance). Memory of Last Cleaning Parameters.
- Heating & Temperature Control – For Steam Cleaners and Heated Ultrasonic Baths. Integrated PTC/SSR Driver (Up to 1500W) with NTC Thermistor Input (Accuracy ±1℃). Adjustable Temperature Range 30–90℃ (Steam Up to 160℃). Over‑Temperature and Dry‑Heating Protection.
- Comprehensive Safety System – Water Level Detection (Float Switch or Conductivity Probe), Door/Lid Lock Interlock (Magnetic Reed or Micro‑Switch), Over‑Load Protection (Current Sensing), and Emergency Stop Button Input. Automatic Shutdown on Faults.
- User Interface & Connectivity – 0.96″–2.4″ OLED/LCD (Optional Touch) Showing Mode, Time, Temperature, and Progress. 3‑6 Membrane Buttons or Capacitive Touch Keys. Optional WiFi/Bluetooth for Remote Monitoring, Cycle Logging, and Maintenance Reminders.
(0 Reviews)
0 Sold
Product Overview
The Cleaning Equipment PCBA is a versatile, fully programmable control board designed for a wide range of industrial, commercial, and household cleaning machines – including ultrasonic cleaners, pressure washers, steam cleaners, carpet cleaners, car wash systems, and parts washers. It centralises timing, temperature regulation, motor/pump control, safety monitoring, and user interface functions into a compact, rugged PCB suitable for wet/dusty environments (conformal coating available).
The global cleaning equipment market is expanding due to rising hygiene standards, industrial automation, and consumer demand for efficient home cleaning tools. This PCBA provides a scalable platform for manufacturers to build reliable, feature‑rich cleaning devices with consistent performance and safety compliance.
