Beauty Device PCBA – Multi‑Function Circuit Board with RF, EMS, LED Phototherapy, Vibration & Thermal Control for Skincare Appliances
No.YQQX016
- Multi‑Technology Integration – Single PCBA Supports RF (Radio Frequency, 0.5–4MHz), EMS Micro‑Current (1–150Hz, 0–100mA), LED Phototherapy (400–850nm), Vibration Massage, Iontophoresis (± ions), Ultrasonic, and Hot/Cold Therapy – Eliminating the Need for Multiple Separate Boards.
- Precise RF & EMS Control – High‑Voltage RF Driver Delivers up to 40V Peak for Deep Dermal Heating (Collagen Stimulation), While Constant‑Current EMS Circuit Provides Adjustable Micro‑Current for Facial Muscle Toning and Lymphatic Drainage.
- Smart LED Phototherapy – Independent Constant‑Current Drivers for 3–7 LED Channels (Red, Blue, Green, Yellow, Purple). Wavelength Accuracy ±10nm Ensures Clinically Effective Photobiomodulation – Red for Anti‑Aging and Collagen Production, Blue for Acne Treatment.
- Intelligent Power & Thermal Management – Lithium Battery Charging (USB‑C, 5V/2A) with Over‑Charge/Discharge/Short‑Circuit Protection. Hot Compress (38–45°C) and Cold Compress (6–20°C) Control Via PTC Heater or TEC Cooler, with NTC Feedback for ±1°C Accuracy.
- User‑Friendly Interface & Memory – Capacitive Touch or Mechanical Buttons with LED Indicators. Optional 0.96″ OLED Display Showing Mode, Intensity, Battery Level. EEPROM Stores Last‑Used Settings for Automatic Recall on Next Power‑on.
(0 Reviews)
0 Sold
Product Overview
The Beauty Device PCBA is a high‑performance, fully customizable circuit board assembly designed for modern multi‑functional skincare appliances. It integrates a comprehensive suite of salon‑grade technologies – RF (radio frequency), EMS (electrical muscle stimulation), LED phototherapy, vibration, iontophoresis, ultrasonic, and hot/cold therapy – into one compact PCBA. This enables manufacturers to produce portable, rechargeable beauty devices that deliver professional results for home use.
We Offer Full Customization Services: Schematic Design, PCB Layout, Component Sourcing, and PCBA Assembly. Contact Us with Your Specific Requirements.
